Yamaha Wabash E Bike

Impervious to terrain conditions, the Wabash is the bicycle equivalent to the word “and”. Road and Mountain. Pedal and Power. Man and Machine. Rock and Roll!  MSRP: 3499

Suggested Use Gravel, Road, Adventure

Sizes Small, Medium, Large Total Weight 42.3 lbs. (L size) Frame Yamaha Hydroformed Aluminum. Internal shift/brake hose routing (hose-clamp guides under top tube for external dropper post configurations) Fork One-Piece Aluminum. 12x100mm Thru-Axle. Fender compatible. Internal brake hose routing Battery Yamaha 500Wh 36V Lithium Ion Drive Unit Yamaha PWSeries SE 3-bolt Mount Crankarm Square Taper Spindle. S=165mm, M,L=170mm Chainring SRAM APEX 1 50t Shifter SRAM APEX 1 HRD Rear Derailleur SRAM APEX 1 Brakes/Rotors SRAM APEX Hydraulic. 160mm Center Lock Rotors Cassette SRAM PG-1130. 11-42t. 11-Speed Chain KMC X11e Hubs Front: 12x100mm TA Rear: 12x142mm TA with integrated speed sensor Rims 32-Hole Dual Channel Welded Pin w/ Eyeleted Spoke Holes 24.5mm External Width, 19mm Internal Width Spokes SUS304 w/ brass nipple Tires/Tubes Maxxis Speed Terraine 700 x 33c TR EXO Headset Integrated bearing with 30mm of spacers Stem 4-bolt, 31.8 clamp dia. S=50mm, M,L=70mm Handlebar Flare Drop. 31.8 dia. S=40cm c-c “width at hood”, 51cm c-c “width at drop” M,L =44cm c-c “width at hood”, 51cm c-c “width at drop” Grips/Tape Padded Cork Tape Seatpost Alloy 30.9, 2-Bolt Tilt Adjustable. S=260mm, M=315mm, L=350mm Seatpost Collar Alloy 2-bolt 35.0mm diameter Saddle Yamaha Off-Road Cro-Mo Rail Wheels and Tires Ready for Off-Road Wide-flare Gravel Handlebar for Added Control Ergonomic Control Switch Triple Sensor System with Rear Hub Speed Sensor Rated Power: 250W (Nominal), 500W (Max.) Max. Torque: 70Nm Max. Cadence Support: 110rpm Max. Speed Support: 20mph 4 Power Assist Modes: ECO+, ECO, STANDARD, HIGH Internal Cable/Housing Routing Dropper Post Compatible Fender and Rear Rack Compatible Accessories Yamaha Keys Yamaha Battery Charger LED Headlamp Bell Handlebar Accessory Mount Warranty 3-Year on Frame, Drive Unit, Battery* Component manufacturer’s warranty byYamaha
